鋁合金門窗加工設備合片機用垂直定位機構托板固定在托板支板上,在托板支板的下面有兩個升降缸,升降缸是由升降缸導軸外套升降缸導套構成,托板支板就固定在兩升降缸導套上,在兩升降缸導套的外壁各鉸接有杠桿,杠桿的支點鉸接有支板,杠桿的另一端與聯動桿鉸接,聯動桿再與油缸的油缸軸鉸接。
Aluminum Alloy doors and windows processing equipment assembling machine with vertical positioning mechanism fixed on the support plate plate plate plate, under the support plate with two lifting cylinder, the lifting cylinder is composed of a guide shaft lifting cylinder jacket lifting cylinder guide sleeve which is fixed on the supporting plate plate two lifting cylinder guide sleeve, a lever on the wall two lift cylinder guide sleeve are respectively hinged hinged lever fulcrum, a support plate, the other end of the lever and the linkage rod hinged linkage rod is hinged with the cylinder cylinder shaft.

另外,在托板的一側還有一個托板定位器.門窗傾斜問題:門窗在安裝完畢后,出現了傾斜、門扇走扇推拉不好的現象,這主要是由于安裝人員在安裝過程中沒有用線墜,靠尺檢查門窗與地面或臺面的垂直度,造成偏差過大.鋁合金門窗加工設備因此安裝門窗時,一定要按安裝規范去做.

In addition, the supporting side and a supporting plate positioner. Doors and windows in the doors and windows tilted: after installation, the door appeared inclined, unable to close properly push and pull bad phenomenon, which is mainly due to the installation personnel did not use wire in the installation process, on foot and ground verticality check doors and windows or table, causing deviation Aluminum Alloy. So the installation of doors and windows and doors processing equipment, must be done by the installation specification.
門窗不水平:門窗安裝后,出現一頭高一頭低、扇和框的縫隙不均勻現象,有時存在上寬下窄或下寬上窄的問題.處理這種問題,首先要測量窗臺或地面的水平度,看一下哪邊高,然后以高點為基準,低的地方用木楔或墊塊臨時固定,以調整窗框的水平度。
The level of windows and doors: doors and windows installed, a large gap appears low, a fan and a frame of uneven, sometimes there are narrow width or narrow width problem. To deal with this problem, we must first measure the window or the ground level, to see which side is high, then the high benchmark wedge block or temporary fixing low places, to adjust the window level.
水平度調好了,窗子就不會出現一邊高一邊低的現象.托板定位器是在步進電機的出軸上固定一垂直的絲杠,在絲杠上通過螺紋連接一個光電傳感器.絲杠采用滾珠絲杠.玻璃鋁條切割裝置由擺臂、A銷軸、夾緊塊、固定塊、鋸片、電機、連接板、A氣缸、底板、支架、接頭、氣缸板、B氣缸、氣缸尾座、B銷軸、墊片和電機接頭組成.軟頭快速連接的裝置,包括燈罩、與帶電線的端子注塑為一體的軟頭,還包括緊套在燈罩尾端外的塑膠卡套。
The level of a good tune, the window will not appear side higher phenomenon. The pallet locator is the stepping motor which is fixed on the shaft of a vertical screw on the screw rod, a photoelectric sensor is connected by screw thread. The best use of the ball screw. The glass aluminum cutting device comprises a swinging arm, a pin shaft, A the clamping block, a fixed block and a saw blade, motor, cylinder, connecting plate, A plate, bracket, joint, cylinder plate, B cylinder, cylinder tailstock, B pin, gasket and motor joint. Quick connecting device of soft head, soft head terminal injection comprises a lamp shade, and charged the line as a whole, also includes a lampshade outside the end of plastic sleeve.
鋁合金門窗加工設備塑膠卡套的外表面上至少有一個凸起點,軟頭的內表面上有寬度與凸起點相適配的軸向?qū)虿奂芭c軸向?qū)虿鄞怪辈⑾嗤ǖ闹雇撇?前出裝置包括平臺、傳送輥和支撐輪,平臺的兩端分別鉸接有轉板,兩轉板之間連接有橫梁,傳送輥設置于橫梁上;平臺與轉板之間設有一組活塞桿、氣缸作為轉板的驅動機構,活塞桿鉸接于平臺上,氣缸鉸接于轉板上.敲打門框要用塑錘輕輕地敲,切不可用鐵錘去敲.
Aluminum Alloy doors and windows processing equipment for plastic sleeve on the outer surface of at least one convex starting point, soft head on the inner surface of the axial direction and the width of the groove is matched with the convex starting point and axial guide groove and vertical thrust groove communicated. Before the device comprises a platform, transfer roller and the support wheel, both ends of the platform the hinged turn plate, a cross beam is connected between the two rotary plate, transfer roller is arranged on the beam; a piston rod and the cylinder as the driving mechanism of transfer plate is arranged between the platform and the transfer plate, the piston rod is hinged on the platform, the cylinder is hinged on the rotary plate. With a plastic hammer to beat doorcase knocked softly that must not be knocked with hammer.
