(1) adjust the position of the compressed cylinder

將鋁合金型材放到該鋁門窗設備的工作臺面上，兩鋸頭的壓緊氣缸調整至對工件壓緊合適的位置，然后固定壓緊氣缸。

The aluminum alloy section is placed on the work surface of the aluminum door and window equipment, and the pressing cylinder of the two saw head is adjusted to the most suitable position for pressing the workpiece, and then the cylinder is fixed and pressed tightly.

（2）調整鋸片進給速度

(2) adjusting feed speed of saw blade;

先以切割鋸出廠的默認鋸片進給速度試機，在試機過程中，如果覺得鋸片的進給速度不合適時，可以調節工進氣缸調速接頭，增大或減少進給速度，就可得到所需要的進給速度。

The first factory default to cutting saw blade feeding speed test machine, the test machine in the process, if the feed speed of the saw blade is not right, can adjust the feeding speed of cylinder joints, increase or decrease the feed speed, feed speed will be needed.



（3）調整鋸削角度

(3) adjust sawing angle;

鋁合金型材精密切割鋸按上述各項調整完畢，檢查符合規定后試運轉30分鐘。

Aluminum alloy profiles, precision cutting saw, according to the above adjustment, inspection compliance with the provisions of the trial operation 30 minutes.

（4）調整設備90°角的切割（鋸片伸出與工作臺面垂直）。

(4) adjust the cutting of equipment at 90 degree angle (saw blade extends vertically to the work surface).

鋁合金型材精密切割鋸出廠前均經調試并經檢驗合格，在此可直接鋸切一鋁合金型，材檢驗其90度角的鋸切面是否符合要求，誤差為±10′。如若不符合要求，可調整限位擋塊上的螺栓。然后再重復鋸切測量，使之滿足要求。注意要鎖緊切割鋸上的螺母。

The precision cutting saw of aluminium alloy profile has been debugged and inspected before leaving the factory. It can be directly cut and cut into an aluminum alloy material to test whether the saw section of the 90 degree angle meets the requirement and the error is + 10'. If the requirement is not met, the bolt on the stop block can be adjusted. Then repeat the cut measurements to meet the requirements. Finally, be careful to lock the nuts on the cutting saw.

（5）調整設備45°角的切割（鋸片伸出與工作臺面夾角成45°時設定為45°）

(5) adjust the cutting of equipment at 45 degrees angle (when the angle between the saw blade extending out and the working table is 45 degrees, set to 45 degrees)

松開工作臺上的鎖緊手柄，擺角氣缸通氣，45度角到位后，鎖緊把手。鋸切型材后檢查是否符合要求（誤差為±10′）。如果不符合要求，可調整限位擋塊上的限位螺釘，重復鋸切、測量，使之滿足要求。然后再鎖緊螺釘上的螺母，擰緊鎖緊手柄。

Loosen the lock handle on the work bench, swing the angle cylinder, ventilate, 45 degrees angle in place, lock the handle. Check the section after cutting to see whether it meets the requirement (the error is + 10 '). If not meet the requirements, you can adjust the limit block on the limit screw, repeated sawing, cutting, measuring, to meet the requirements. Then lock the nut on the screw and tighten the handle tightly.

（6）調整型材切割長度。

(6) adjust the cutting length of the profile.

角度調整完畢后，應調整鋁合金型材的切割長度。拉動把手帶動右鋸頭沿圓導軌移動至準確位置（看標尺指針），刻度尺指示長度即鋁合金型材短邊的長度。切割完成后，如切割后型材的長度與要求長度有偏差，應進行微調，微調時，擰緊剎車可調手炳，轉動微調手炳至要求尺寸。

After the angle adjustment is finished, the cutting length of aluminum alloy profile should be adjusted. The pulling handle drives the right saw head to move to the correct position along the circular guide rail (see the ruler pointer), and the graduation ruler indicates the length, that is, the length of the short edge of the aluminum alloy profile. After finishing cutting, such as cutting length and the length of required profile deviation should be fine-tuning, fine-tuning, tighten the brake adjustable handle, rotate the handle to the required size adjustment.
