1、鋸床上的液壓油應加足,滑動和轉動部位抹上一層機油;
1, the hydraulic oil on the sawing machine should be added, sliding and rotating part of the oil;
2、帶鋸床裝上鋸帶,調節(jié)漲緊裝置使鋸帶漲緊達到合適程度,調節(jié)好行程開關觸頭剛好碰到擋鐵,處于開啟狀態(tài);
2. The sawing machine is mounted on the saw belt, adjusting the tightening device to make the saw belt tighten to the right degree.
3、接上電源必須標準可靠,開啟電源開關,開動鋸試車,按照標牌上所注明旋向校正接線,同時聽其響是否正常;
3, the power supply must be reliable, open the power switch, open the saw test, according to the sign on the direction of the rotation correction connection, at the same time listen to its sound is normal;
4、檢查升、降油缸裝置,檢查鋸弓抬起和落下,是否可靠靈活;
4, check up and drop the oil cylinder device, check the saw bow to lift and drop, whether it is reliable and flexible.
5、檢查夾緊、放松油缸裝置,檢查夾緊時是否夾緊可靠,放松是否靈活;
5, check the clamping and relaxation of the oil cylinder device, check the clamping when clamping reliability, relaxation is flexible;
6、在主電機電源開關開啟后,水泵相應同時啟動,冷卻系統(tǒng)正常運轉.調試閥門,檢查冷卻液是否流暢;
6. After the main motor power switch is opened, the pump starts at the same time, the cooling system operates normally. The valve is debugged to check whether the coolant is fluent.
7、做好以上準備工作后,裝料夾緊鎖定,進行試鋸削.
7. After doing the above preparation, the loading is clamped and locked, and the test sawing is carried out.
