鋁合金門窗加工設備玻璃鋁條切割流程
2018-02-02
點擊數：1802
鋁合金門窗加工設備合片機用垂直定位機構托板固定在托板支板上，在托板支板的下面有兩個升降缸，升降缸是由升降缸導軸外套升降缸導套構成，托板支板就固定在兩升降缸導套上，在兩升降缸導套的外壁各鉸接有杠桿，杠桿的支點鉸接有支板，杠桿的另一端與聯動桿鉸接，聯動桿再與油缸的油缸軸鉸接；另外，在托板的一側還有一個托板定位器。
Aluminum Alloy doors and windows processing equipment assembling machine with vertical positioning mechanism fixed on the support plate plate plate plate, under the support plate with two lifting cylinder, the lifting cylinder is composed of a guide shaft lifting cylinder jacket lifting cylinder guide sleeve which is fixed on the supporting plate plate two lifting cylinder guide sleeve, a lever on the wall two lift cylinder guide sleeve are respectively hinged hinged lever fulcrum, a support plate, the other end of the lever and the linkage rod hinged linkage rod and cylinder shaft is hinged with the cylinder; in addition, the supporting side and a plate positioner.
門窗傾斜問題：門窗在安裝完畢后，出現了傾斜、門扇走扇推拉不好的現象，這主要是由于安裝人員在安裝過程中沒有用線墜，靠尺檢查門窗與地面或臺面的垂直度，造成偏差過大。鋁合金門窗加工設備因此安裝門窗時，一定要按安裝規范去做。
Question: doors and windows in the doors and windows tilted after installation, the door leaf tilt, unable to close properly push and pull bad phenomenon, which is mainly due to the installation personnel did not use wire in the installation process, on foot and ground verticality check doors and windows or table, causing the large deviation. The aluminum alloy door and window processing equipment must be done according to the installation specification when the doors and windows are installed.
門窗不水平：門窗安裝后，出現一頭高一頭低、扇和框的縫隙不均勻現象，有時存在上寬下窄或下寬上窄的問題。處理這種問題，首先要測量窗臺或地面的水平度，看一下哪邊高，然后以高點為基準，低的地方用木楔或墊塊臨時固定，以調整窗框的水平度。
The level of windows and doors: doors and windows installed, a large gap appears low, a fan and a frame of uneven, sometimes there are narrow width or narrow width problem. To deal with this problem, we must first measure the window or the ground level, to see which side is high, then the high point for the benchmark, or wedge block temporary fixation with low place, in order to adjust the window level.
水平度調好了，窗子就不會出現一邊高一邊低的現象。托板定位器是在步進電機的出軸上固定一垂直的絲杠，在絲杠上通過螺紋連接一個光電傳感器。絲杠采用滾珠絲杠。玻璃鋁條切割裝置由擺臂、Ａ銷軸、夾緊塊、固定塊、鋸片、電機、連接板、Ａ氣缸、底板、支架、接頭、氣缸板、Ｂ氣缸、氣缸尾座、Ｂ銷軸、墊片和電機接頭組成。
The level is well adjusted, the window will not appear on the side of the side of the low side of the phenomenon. The bracket locator is a vertical screw that is fixed on the exit shaft of the stepping motor, and a photoelectric sensor is connected through the screw thread on the screw thread. The ball screw is best used for the screw. The glass aluminum strip cutting device is composed of swing arm, A pin, clamping block, fixed block, saw blade, motor, connecting plate, A cylinder, bottom plate, bracket, joint, cylinder plate, B cylinder, cylinder tail seat, B pin, gasket and motor joint.
軟頭快速連接的裝置，包括燈罩、與帶電線的端子注塑為一體的軟頭，還包括緊套在燈罩尾端外的塑膠卡套，鋁合金門窗加工設備塑膠卡套的外表面上至少有一個凸起點，軟頭的內表面上有寬度與凸起點相適配的軸向?qū)虿奂芭c軸向?qū)虿鄞怪辈⑾嗤ǖ闹雇撇邸?/span>
Quick connecting device of soft head, soft head terminal injection comprises a lamp shade, and charged the line as a whole, also includes a lampshade outside the end of the plastic sleeve, Aluminum Alloy doors and windows processing equipment for plastic sleeve on the outer surface of at least one convex starting point, soft head with an axial guide groove width and convex the starting point is matched with the guide groove and the vertical and axial thrust on the inner surface of groove.
前出裝置包括平臺、傳送輥和支撐輪，平臺的兩端分別鉸接有轉板，兩轉板之間連接有橫梁，傳送輥設置于橫梁上；平臺與轉板之間設有一組活塞桿、氣缸作為轉板的驅動機構，活塞桿鉸接于平臺上，氣缸鉸接于轉板上。敲打門框要用塑錘輕輕地敲，切不可用鐵錘去敲。
A device includes a platform, transfer roller and the support wheel, both ends of the platform are respectively articulated with the rotating plate, a cross beam is connected between the two rotary plate, transfer roller is arranged on the beam; a piston rod and the cylinder as the driving mechanism of transfer plate is arranged between the platform and the transfer plate, piston rod hinged hinged on the Yu Ping bench, cylinder turn on the board. The knocking door frame should be knocked lightly with a plastic hammer, and the hammer should not be knocked on.
