DJM-450 鋁門窗全自動角碼鋸是濟南科萊機器有限公司根據DJM-450 鋁門窗全自動角碼鋸技術為廣大的客戶設計的理想產品，DJM-450 鋁門窗全自動角碼鋸的產品廣泛應用于工業、農業、礦山、交通、建筑、科研、建筑、化工、紡織等各行各業。 ☆該機主要用于鋁 門窗角碼型材下料

DJM-450 aluminum doors and windows automatic corner saw Ji'nan Kelai machine limited company according to the optimal DJM-450 aluminum doors and windows automatic corner saw ideal technology products for customers to design the majority of the DJM-450 products, aluminum doors and windows automatic corner saws are widely used in industry, agriculture, mining, transportation, construction, scientific research, construction, chemical, textile and other industries. This machine is mainly used for aluminum doors and windows, corner cutting

采用角度可調壓緊技術，調整快捷、高效。

Adopts adjustable angle pressing technology, fast and efficient adjustment.

進給運動副采用直線運動軸承，運動阻力小，加工精度高。

The feed motion pair adopts a linear motion bearing, which has small movement resistance and high machining precision.
刀具采用硬質合金鋸片，切割速度高，操作方便、安全可靠。
The cutting tool uses the hard alloy saw blade, the cutting speed is high, the operation is convenient, the safety and reliability.
預設切割長度，數字設定切割數量，完成自動停機。
The cut length is preset, the number is set to cut the number of cutting, and the automatic shutdown is completed.
適合鋁門窗大批量角碼生產的切割。
Suitable for cutting aluminum doors and windows mass production work.
電路系統中安裝了電動機相序保護器，提高了系統的安全性。
The electric motor phase sequence protector is installed in the circuit system, which improves the security of the system.
（1）技術參數
(1) technical parameters
切割型面的平面度：0.1mm
Flatness of the cutting surface: 0.1mm
切割型面的垂直度：0.1mm
The perpendicularity of the cutting surface: 0.1mm
切割型面的粗糙度：Ra12.5μm
The roughness of the cutting surface: Ra12.5 mu m
回退速度： 0-3(m/min)
Back speed: 0-3 (m/min)
工進速度：0~3(m/min)
Speed of work: 0~3 (m/min)
動下料長度： 0~150(mm)
The length of moving material: 0~150 (mm)
大加工角碼規格：120x120x40(mm)（單邊 x 單邊 x 厚度）
Large processing angle specifications: 120x120x40 (mm (x) unilateral unilateral x thickness)
輸入功率：2.2kw
Input power: 2.2kw
耗氣量：200L /min
Gas consumption: 200L /min
主機外形尺寸：1570x995x1545(mm)
Host size: 1570x995x1545 (mm)
電源：380V/50Hz
Power: 380V/50Hz
環境溫度：15~40 ℃
Ambient temperature: 15~40 C
氣源壓力：Air 0.5~0.7(Mpa)
Gas pressure: Air 0.5~0.7 (Mpa)
