設備裝有四個機頭,其左下機頭為固定機頭,左上、右上、右下為可移動機頭,右上和右下機頭可隨移動橫梁左右移動,可方便的根據窗框的規格進行精確調整.橫梁移動為手動方式,安全方便.左上和右上可通過電動葫蘆來調節.
The equipment is equipped with four head, the left head is fixed on the head, left, right, right to the movable head, right upper and lower right head can move along with the moving beam, can be conveniently according to the specifications of the window frame adjust the moving beam. For the manual mode, the upper left and right is safe and convenient. Can be adjusted by electric hoist.
右上和左上機頭裝有速差防墜器,在緩慢升降時,速差防墜器連接繩可隨機頭緩慢移動,如果機頭急速下降時,速差防墜器工作,從而保護設備和操作人員的安全.

The upper right and left upper part is equipped with speed difference anti falling device. When slow rising and falling, the speed difference anti dropping connector rope can move slowly with random head. If the head goes down rapidly, the speed difference anti falling device works, so as to protect the safety of the equipment and operators.

鋁木門窗組框機主要結構
The main structure of the frame machine for aluminum and wood doors and windows
該機由四個機頭、床身、液壓系統、傳動系統、電氣箱等主要部分組成.
The machine consists of four main parts, such as head, bed, hydraulic system, transmission system, electric box and so on.
鋁木門窗組框機安裝與保管
Installation and storage of the frame machine for aluminum and wood doors and windows
機床運到用戶使用地點,如無運輸損傷,即可使用搬運工具將機床移至安裝位置.
If the machine is transported to the user's place of use, if there is no transportation damage, the machine can be moved to the installation position using a handling tool.
1、機床應安裝在無腐蝕性氣體有堅硬平坦的混凝土地面的廠房?jī)?nèi).將機床床身下的調平底座支好,機床調至水平,緊固調整螺絲的鎖緊螺母,即完成調平工作,可通電通氣試機.
1, the machine tool should be installed in the workshop with no corrosive gas and hard and flat concrete floor. The leveling base under the machine bed is supported, the machine tool is adjusted to the horizontal level, the fastening nut of fastening screw is adjusted, that is, the leveling work is completed, and the ventilating test machine is available.
2、接電:三相四線 380V 50Hz
2, connection: three phase four line 380V 50Hz
3、接地:
3. Earthing:
機床床身必須接地,接地線采用黃綠雙色多股絞合軟銅體(絕緣體),其截面積為2.5平方毫米,接地后機身與主接地點之間的電阻應小于0.1歐姆.
The machine tool bed must be grounded, and the grounding wire is yellow green, double colored, multi stranded, soft copper body (insulator). The sectional area is 2.5 mm2. The resistance between the fuselage and the main grounding point after grounding is less than 0.1 ohms.
4、接氣
4, air
工作氣壓0.5-0.8MPa.把氣源接在氣源處理器的接頭上,檢查氣動系統有無漏氣現象.
The working pressure 0.5-0.8MPa. connects the gas source to the joint of the gas source processor to check the air leakage of the pneumatic system.
