適用于鋁門窗及幕墻型材的切割,進給系統采用進口直線導軌運動副,精度高,穩定性好。右機頭進給導軌滾珠絲供運動形式,船東精度高,定位準確,工作平穩。該機采用數控技術,可完成型材不同規格尺寸的自動下料。
It is suitable for cutting aluminum doors and windows and curtain wall sections. The feed system adopts imported linear guide motion pair, which has high precision and good stability. The right head feed guide rolling ball wire for movement form, the ship owner has high precision, accurate positioning and smooth work. The machine uses numerical control technology to complete the automatic blanking of different specifications and sizes of the profiles.
兩鋸頭可自動轉換角度,實現任意角度切割。原裝進口硬質合金鋸片,加工精度高,耐用度高。進口直線軸承運動副,使工作精度穩定。高精度主軸使鋸片轉動穩定。氣液阻尼缸實現進給調速均勻,運動平穩。
The two sawing head can automatically transform the angle to realize the arbitrary angle cutting. The original imported carbide saw blade has high processing precision and high durability. The moving pair of linear bearings is imported to make the work precision stable. High precision spindle makes the saw blade steady. The air - liquid damping cylinder realizes the uniform speed control and smooth movement.
主要技術參數：
Main technical parameters:
工作氣壓 0.4-0.6 MpaWorking pressure 0.4-0.6 Mpa

輸入電源 380V 50HZ
Input power 380V 50HZ
耗氣量 200 L/min
Gas consumption 200 L/min
輸入功率 5.9KW
Input power 5.9KW
鋸片規格 Φ500×Φ30×4.5
Saw blade specification of 500 x 30 x 4.5
鋸片轉速 3100 r/min
The speed of the saw blade is 3100 r/min
切削寬度 135 mm
Cutting width is 135 mm
切削高度 200 mm
Cutting height 200 mm
雙切長度 400-4200 mm
Double tangent length 400-4200 mm
外形尺寸 5500×1700×1800 mm

Shape size 5500 x 1700 x 1800 mm
重量 2100 kg
Weight 2100 kg
