1、分析中空玻璃生產線實際構造和運動情況，查明該機構由多少個構件織成，找出機架及原動件，根據相連接兩構件間接觸情況及相對運動件質，確定各個運動副類型，并安裝順序標上字母。
1, analysis of hollow glass production line structure and actual movement situation, find out the mechanism by the number of components made out of the original frame and, according to the connection between two members contact and relative motion, determine the motion type and installation sequence of letters.
2、分析原動部分運動經過傳動部分傳遞到工作部分過程。從原動件開始到各個從動件，沿著運動傳遞路線，并且按照在各構件上標上數字編號。
2, analysis of the motion driving part through the transmission part of the transfer to the work process. From the original to each follower motion along the route, and in accordance with the number of components in superscript numbers.

3、選擇與之多數構件的與之相平行平面作為繪制機構運動簡圖投影面。

3, the parallel plane of the majority of the components is chosen as the projection surface of the drawing mechanism.
4、選樣比例要合適，根據中空玻璃生產線運動尺寸，確定各運動副之間相對位置，用規定符號將各運動副表爾出來，用直線或曲線將向一構件上各運動副元素連接起來，用箭頭標注機構原動件在所示位置時運動方向，繪制出所要畫機構運動簡圖。
4, select suitable proportion, according to the insulating glass production line movement size, determine the relative position between the pair, with each pair rule table, out with a straight line or curve will be linked to the movement of a component element, marked by arrows mechanism of the motion in the position shown in the direction. Draw to draw the movement diagram.
在繪制過程中要注意：轉動副的小圓，它要畫在轉動副兩構件相對的中心位置，這是為了準確地表達中空玻璃生產線構件間的相對運動，而移動副的導路與組成移動副兩構件相對移動方向要一致；表示高副的曲線，其曲率中心的位置也要和實際輪廓的曲率中心—致。
Note: in the process of drawing revolute round, it will draw in the center position of the rotary member relative to the two side, this is in order to accurately express the relative motion of insulating glass production line between components, and the moving guide way and the composition of the mobile side two side member relative moving direction to be consistent; the curve indicates a high side the center of curvature, the curvature center of the will and the actual contour caused by.
