1、調整壓緊氣缸的位置
1. Adjust the position of compressed air cylinder
將型材放到該機工作臺面上，兩鋸片的夾壓緊氣缸調整至對工件壓緊最合適的位置，然后固定壓緊氣缸。
Put the profiles on the working table of the machine, adjust the clamping cylinder of the two saw blades to the most suitable position for pressing the workpiece, and then fix and press the cylinder tightly.
1、鋸片進給速度的調節(jié)
1. Adjustment of saw blade feed speed
在試機過程中，如果覺得鋸片的進給速度不合適時，可以調節(jié)工進缸調速接頭，使進給速度增大或減小，就可得到所需要的進給速度。
During the testing process, if the feeding speed of the saw blade is not suitable, the speed regulating joint of the work intake cylinder can be adjusted, and the feed speed is increased or decreased, so the required feed rate can be obtained.
2、鋸削角度調整

2, sawing angle adjustment

機床按上述各項調整完畢，并檢查符合規(guī)定后試運轉30分鐘，如果沒有發(fā)生異?，F象，就可進行以下調試。
The machine tool has been adjusted according to the above, and checked after the test run 30 minutes, if there is no abnormal phenomenon, you can carry out the following debugging.
2.1、 90°角的調整(鋸片伸出與工作臺面垂直)
2.1, 90 degree angle adjustment (saw blade extends to the working surface vertical)
機床出公司前均調試并經檢驗合格,在此可直接鋸切一型材檢驗90°角的鋸切面是否符合要求,機床鋸切初始角度設為90°,誤差為±10ˊ。如若不符合要求，可調整擺角板下面的螺栓的高低，重復鋸切測量，使之滿足要求。然后鎖緊其上的螺母。
A machine before the company are debugging and passed the test, this can be directly cutting a test section 90 angle cutting surface meets the requirements, the sawing machine initial angle is set to 90 degrees. The error is about 10'. If not meet the requirements, you can adjust the height of the bolt below the swing plate, repeat sawing measurement, so that it meets the requirements. Then lock the nut on it.
2.2、 45°角度的調整(鋸片伸出與工作臺面夾角成45°時設定為45°，下同)
Adjust the angle of 2.2 and 45 degrees (when the angle between the protrusion of the saw blade and the working table is 45 degrees, set to 45 degrees, the same below)
松開工作臺上的鎖緊手柄，轉動手柄，抽出支撐桿再轉動手柄，使之擺至45°角鋸切型材，檢驗其45°是否符合要求，誤差為±10。如果不符合要求，可調整拖板上的限位螺栓的高低，再重復鋸切、測量，使之滿足要求，然后再鎖緊螺栓上的螺母，擰緊鎖緊手柄。
The locking handle on the worktable is loosened, the handle is rotated, the supporting rod is drawn out, and the handle is turned, so that the saw bar is cut to the angle of 45 degrees, and whether the 45 degree meets the requirement is checked, and the error is 10. If not meet the requirements, you can adjust the height of the limit bolt on the carriage, and then repeat sawing, measuring, so as to meet the requirements, and then lock the nut on the bolt, tighten the handle tightly.
2.3、-45°角度調整
2.3, -45 degree angle adjustment
松開鎖緊手柄，轉動手柄，把擺角板轉至大于-45°時插入定位桿，然后手柄回轉擺角板壓在定位桿上，鋸切一型材，檢驗其45°是否符合要求，誤差10°，如果不符合要求，可調整扇形塊上的限位螺釘的高低，重復鋸切、測量、使之滿足要求，然后再鎖緊螺釘上的螺母，擰緊鎖緊手柄。
Loosen the locking handle, the handle is rotated to swing angle plates to more than -45 degrees are inserted into the positioning rod, and the handle rotary swing angle of pressure plate on the positioning rod, sawing a profile, test whether the 45 degrees to meet the requirements, the error of 10 degrees, if you do not meet the requirements, can adjust the level of fan-shaped block limit screw, sawing, repeated measurement, so as to meet the requirements, then the lock nut on the screw and tighten the locking handle.
3、切削型材長度調整
3, cutting profile length adjustment
角度調整完畢后，應調整工件的切割長度。撥動“拖板選擇”開關至“左”或“右”位置。按下“拖板啟動”按鈕，使鋸頭運動至所需要加工長度的近似位置，松手，在把“拖板選擇”開關撥至“?！蔽恢?。轉動手輪，同時看著游標尺，使右機頭定位至準確位置，刻度尺指示長度就是工件長邊的長度。
After adjusting the angle, the cutting length of the workpiece should be adjusted. Toggle the carriage selection switch to the left or right position. Press the start button of the carriage, move the saw head to the approximate position of the required length, and let go of the switch to the stop position. Turn the handwheel, and watch the ruler at the same time, so that the right head is positioned to the correct position, and the scale indicates that the length is the length of the long side of the workpiece.
4、操作
4, operation
開總電源機關→調整二機頭角度→調整副標尺箭頭→機頭選擇置“雙”位置→選擇拖板電機方向→啟動拖板電機→拖板位置手動微調→右機頭剎緊→啟動鋸切電機→放料→旋轉旋鈕夾緊→按動工進按鈕→松開工進按鈕→松開夾緊→取料
The total power to adjust the opening angle and organ adjustment vice ruler, arrow head selection set "double" position, choose to start the carriage motor, motor carriage, carriage direction position, manual adjustment right head locking to start cutting motor, feeding, clamping, rotating the knob to release the button according to start feeding button, loosen the clamping and Reclaimer
5、停機
5, stop
停機前，機器應空載運行2分鐘，觀察機器運行狀況，確定無異常后，關閉電源，切斷氣源停機。
Before shutdown, the machine should run no-load for 2 minutes, observe the operation of the machine, determine the no exception, turn off the power supply, cut off the gas supply stop.
